Then, this wave guiding structure is extended to the design of a six-element leaky wave antenna array with a complete size of 25.6 mm × 80.6 mm, which is working at Ku band from 12.0 GHz to 12.8 GHz and achieving a bandwidth of about 0.8 GHz, a gain of 11.36 dBi, and an efficiency of ca. Since the bandgap of these mushroom-like units is calculated with a coverage of the channel working band, these units are of great importance on ensuring the transmission efficiency and eliminating the coupling effect between channels. The guiding channel is developed on the full planar dielectric substrate and aligned with electromagnetic bandgap (EBG) units. Simulation enables the use of virtual prototyping.A new type of wave guiding structure is proposed is this paper.
